COMPRESSION ISOLATION VALVE
MAX-UK012

Welcome to CFITMAX. We are Expert in Brass Compression Ball Valves and MGPS Isolation Ball Valves that are designed to work with Medical Gas Pipeline Systems (MGPS). Being a committed manufacturer, supplier, and dealer, we make sure that all our products are packed under medical grade and have been well tested on their performance and durability. Our 15MM widely trusted isolation valves already are already supplying to major industrial and medical zones of Faridabad, Panipat, Soniphat, Rai, Kundli, Bawal, Ambala Cantt, and Gurgaon in Haryana and Jalandhar in Punjab where we haves been one of the proud suppliers of several Hospital projects and healthcare infrastructures.

MATERIAL TEST SPECIFICATIONS

Body: 100% Brass

Compression Olive: Brass

Seal: PTFE

Ball: Chrome Plated Brass

O-Ring: NBR

Stem: Brass

Handle: NBR

Nut: Steel

BS864/2 Compression Nut: Steel

SPECIFICATIONS

PN 30 Rating

Compression Ends to BS864/2

Produced EN 1254-2 Equivalent

Full Bore

T-Handle Type Operation

Quarter Turn Operation

High Quality PTFE Seal

Nickel Plated Finish

Maximum pressure Conditions:

30 Bar – Temp up to 30° C

8 Bar – Temp up to 120° C
